Model | Điện đầu vào | Công suất đầu vào (KW) | Dòng điện, A | Môi chất lạnh
(R134 / KG) |
Công suất sấy (KW) | Công suất làm lạnh (KW) | Công suất hút ẩm (L nước / H) | Lưu lượng gió nóng (m³ / H) | Kích thước máy sấy (mm) | Kích thước buồng sấy (mm) | Công suất sấy kg/mẻ |
GND-300H | 220 V, 1PH, 50 / 60HZ | 5,5 | 25.0A | 2,5 | 10,5 | 7,8 | 12,0 | 23600-12800 | 1650 * 856 * 1280 | 3800 * 2190 * 2200 | 300 |
380V, 3PH, 50 / 60HZ | 5,5 | 11,0 A | 2,5 | 10,5 | 7,8 | 12,0 | 23600-12800 | 1650 * 856 * 1280 | 3800 * 2190 * 2200 | ||
GND-500H | 380V / 3PH / 50HZ
460-480V / 3PH / 60HZ |
6,9 | 14,0 A | 3,8 | 16.0 | 12,5 | 20.0 | 23600-12800 | 1650 * 856 * 1280 | 3800 * 2190 * 2200 | |
GND-600H | 9,5 | 19,0 A | 4.0 | 21.0 | 18,0 | 25,0 | 47200-25600 | 1650 * 1056 * 1280 | 6150 * 2190 * 2200 | 600 | |
GND-1200H | 19,4 | 39,0 A | 8,0 | 42,0 | 32,0 | 50,0 | 70800-38400 | 2089 * 1260 * 1580 | 6350 * 3230 * 2200 | 1200 | |
GND-1500H | 21.8 | 44.0A | 9.0 | 50,0 | 40,0 | 60,0 | 76500-54000 | 2089 * 1260 * 1580 | 6350 * 4670 * 2200 | ||
GND-300HD | 11.0 | 22,0 A | 5.0 | 21.0 | 15.6 | 24.0 | 47200-25600 | 1650 * 856 * 1280 | 7050 * 2190 * 2200 | ||
GND-500HD | 13.8 | 28,0 A | 7.6 | 32,0 | 25,0 | 40,0 | 47200-25600 | 1650 * 856 * 1280 | 7050 * 2190 * 2200 | ||
GND-600HD | 19.8 | 37,0 A | 8,0 | 42,0 | 36,0 | 50,0 | 47200-25600 | 1650 * 1056 * 1280 | 10100 * 2190 * 2200 | ||
GND-1200HD | 32.8 | 66,0 A | 16.0 | 84.0 | 64,0 | 100,0 | 70800-38400 | 2089 * 1260 * 1580 | 10750 * 3230 * 2200 | ||
40,0 | 80,0 A | 16.0 | 84.0 | 64,0 | 100,0 | 120000-72000 | 2089 * 1260 * 1580 | 10750 * 3230 * 2200 | 1600 | ||
GND-1500HD | 43,6 | 88.0A | 18,0 | 100,0 | 80,0 | 120,0 | 153000-120000 | 2089 * 1260 * 1580 | 12900 * 4670 * 2200 |
